How to Configure FastEthernet / Serial Interface of Cisco Router with GNS3 | SYSNETTECH Solutions

Skip ad
166 Views

  • Thanks! Share it with your friends!

    You disliked this video. Thanks for the feedback!

monica
Published
This video shows you the steps to configure the interfaces of the Cisco Router on a network topology using GNS3.

✅ S U B S C R I B E ► http://goo.gl/8d0iG9
✅ Article ► https://www.sysnettechsolutions.com/en/configure-interface-on-cisco-router/

To configure the Cisco Router's #FastEthernet, #GigabitEthernet, or Serial interfaces basically:

Step 1: First open the #GNS3 program and create a new topology, then add a Cisco Router, Switch, and one virtual machine.

Step 2: Connect all devices in the work area with the wiring.

Step 3: Run your virtual computer on VMware and configure VMnet settings according to the network topology you created.

Step 4: Now open the CLI prompt to assign an IP address to the Cisco Router and open the port and execute the commands in the 2:20 timeframe in order.

Step 5: After performing the above commands, you will see that the operation will be successful when you ping the Router from the virtual machine.

Step 6: To open any interface of the Router, you must use the command no shutdown in that interface.

Step 7: Don't forget to subscribe to our YouTube channel for more videos on Cisco training with GNS3!
