Steps :
Step 1 : Adding Addresses to each router and make sure there a connection between them (sorry )
Step 2 :
Installing SNMP and some optional SNMP utilities is as simple as running one command:
# yum -y install net-snmp net-snmp-utils
Step 3 :
On your Cisco device, enable snmp using the following:
#snmp-server community public #[change 'public' if necessary] ro | rw
#snmp-server host IP_of_ZabbixServer version 2c public udp-port 161
Step 4:
Test the SNMP Configuration
Now let’s test the SNMP configuration… try running the following command:
snmpwalk -v 2c -c sysadminit ip@
Step 5 :
Create a Host for Cisco Router
click on Configuration = Host =Create Host
now we are in Host tab
-Host name: set name for you client
-Groups: choose a group for you client
-SNMP interfaces : input your client ip
go to Template tab = click on Select = double click on “Template SNMP Device”
= go to Macros tab
-Macro: {$SNMP_COMMUNITY}
-Value: type your community name, mine is “public”
= click on Add =click on Add button
Step 1 : Adding Addresses to each router and make sure there a connection between them (sorry )
Step 2 :
Installing SNMP and some optional SNMP utilities is as simple as running one command:
# yum -y install net-snmp net-snmp-utils
Step 3 :
On your Cisco device, enable snmp using the following:
#snmp-server community public #[change 'public' if necessary] ro | rw
#snmp-server host IP_of_ZabbixServer version 2c public udp-port 161
Step 4:
Test the SNMP Configuration
Now let’s test the SNMP configuration… try running the following command:
snmpwalk -v 2c -c sysadminit ip@
Step 5 :
Create a Host for Cisco Router
click on Configuration = Host =Create Host
now we are in Host tab
-Host name: set name for you client
-Groups: choose a group for you client
-SNMP interfaces : input your client ip
go to Template tab = click on Select = double click on “Template SNMP Device”
= go to Macros tab
-Macro: {$SNMP_COMMUNITY}
-Value: type your community name, mine is “public”
= click on Add =click on Add button
