Fiber Optics #14 Electromagnetic Analysis of Waveguides 04
In 14th lecture of fiber optics we will discuss more about electromagnetic analysis of waveguides. Transcendental equations in normalized parameters have been formed. b-V plots and modal fields have been studied.

01:22 Highly multi mode waveguide
05:34 Example
07:28 Guided Modes of a planar waveguide, Normalized parameters
10:47 Trancendental equations in normalized parameters
13:35 b-V curves
19:45 Modal-fields
27:52 Penetration depth

Fiber Optics/ Optical Fiber Lectures from IIT for GATE, IES, ESE @ https://goo.gl/ngcoSi
