- Would you like to segregate traffic between devices?
- Do you want to reduce the broadcast domain on your network?
- Do you want to block traffic between VLANs?

_______________________________________________________________________________________
Cisco Meraki Training
https://www.youtube.com/playlist?list=PLPE44QtHLnZRrQwjx2K5l2XQsh0JjtxlL
_______________________________________________________________________________________

In this opportunity, we are going to configure several subnets that will be segregated using VLANs. With this configuration, we will ensure the clients will be Layer 2 isolated.

To configure VLANs, we will go to Security & SD-WAN - Configure - Addressing & VLANs, check the box to enable VLANs and fill the necessary fields. Additionally, you can assign the VLANs to the ports based on your needs.

________________________________________________________________________________________
Cisco Meraki documentation:

- Configuring VLANs on the MX Security Appliance
https://documentation.meraki.com/MX/Networks_and_Routing/Configuring_VLANs_on_the_MX_Security_Appliance

If you encounter any issues configuring VLANs, feel free to post a comment with the information and I will help you to move forward.
